Titan Mosaic - Feb 2005 Target Name:   Titan Spacecraft:   Cassini Orbiter Instrument:   Imaging Science Subsystem - Narrow Angle Produced by:   NASA/JPL/Space Science Institute Copyright:  NASA Copyright Free Policy Cross Reference:   PIA06185 Date Released:  17 February 2005

• Titan
• Cassini At Titan
• Huygens Lands on Titan

This mosaic of Titan's surface was made from 16 images. The individual images have been specially processed to remove effects of Titan's hazy atmosphere and to improve visibility of the surface near the terminator (the boundary between day and night).

During Cassini's first close flyby of Titan in October 2004, many clouds were seen near the south pole; in the December flyby many clouds were seen at mid-latitudes (see PIA06157). During this flyby, only a few small clouds near the south pole were noted.

Imaging coverage during this flyby included improved looks at territory to the north and west of Xanadu, the large bright white area.

The images were taken with the Cassini spacecraft narrow angle camera through a filter sensitive to wavelengths of polarized infrared light and were acquired at distances ranging from approximately 226,000 to 242,000 kilometers (140,000 to 150,000 miles) from Titan. Resolution in the images is about 1.3 kilometers (0.8 miles) per pixel.
