Outer B Ring Edge Target Name:   Saturn Spacecraft:   Cassini Orbiter Instrument:   Imaging Science Subsystem - Narrow Angle Produced by:   NASA/JPL/Space Science Institute Copyright:  NASA Copyright Free Policy Cross Reference:   PIA06535 Date Taken:   29 October 2004 Related Documents Saturn Saturn's Magnificent Rings Download Options Name Type Width x Height Size PIA06535.jpg JPEG 640 x 640 62K PIA06535.jpg JPEG 1024 x 1024 149K PIA06535.tif TIFF 1024 x 1024 1.05 MB This close-up of the lit side of Saturn's outer B ring and the Cassini Division looks something like a phonograph record. There are subtle, wavelike patterns, hundreds of narrow features resembling a record's 'grooves' and a noticeable abrupt change in overall brightness beyond the dark gap near the right. To the left of the gap is the outer B ring with its sharp edge maintained by a strong gravitational resonance with the moon Mimas. To the right of the Huygens Gap are the plateau-like bands of the Cassini Division. The narrow ringlet within the gap is called the Huygens ringlet. The image was taken in visible light with the Cassini spacecraft narrow angle camera on Oct. 29, 2004, at a distance of about 819,000 (509,000 miles) from Saturn. The image scale is 4.5 kilometers (2.8 miles) per pixel.
