1994 Clementine image of moon with Mare Nubium labeled
1994 Clementine image of the moon with Mare Nubium labeled. LRO's first lunar images show an area near this region.
Credit: NASA

NASA's LRO Spacecraft Sends First Lunar Images to Earth

July 02, 2009

NASA's Lunar Reconnaissance Orbiter, or LRO, has transmitted its first images since reaching lunar orbit June 23. The spacecraft has two cameras -- a low resolution Wide Angle Camera and a high resolution Narrow Angle Camera. Collectively known as the Lunar Reconnaissance Orbiter Camera, or LROC, they were activated June 30. The cameras are working well and have returned images of a region a few kilometers east of Hell E crater in the lunar highlands south of Mare Nubium.

As the moon rotates beneath LRO, LROC gradually will build up photographic maps of the lunar surface.

"Our first images were taken along the moon's terminator -- the dividing line between day and night -- making us initially unsure of how they would turn out," said LROC Principal Investigator Mark Robinson of Arizona State University in Tempe. "Because of the deep shadowing, subtle topography is exaggerated, suggesting a craggy and inhospitable surface. In reality, the area is similar to the region where the Apollo 16 astronauts safely explored in 1972. While these are magnificent in their own right, the main message is that LROC is nearly ready to begin its mission."

LRO will help NASA identify safe landing sites for future explorers, locate potential resources, describe the moon's radiation environment and demonstrate new technologies.

The satellite also has started to activate its six other instruments. The Lunar Exploration Neutron Detector will look for regions with enriched hydrogen that potentially could have water ice deposits. The Cosmic Ray Telescope for the Effects of Radiation is designed to measure the moon's radiation environment. Both were activated on June 19 and are functioning normally.

Instruments expected to be activated during the next week and calibrated are the Lunar Orbiter Laser Altimeter, designed to build 3-D topographic maps of the moon's landscape; the Diviner Lunar Radiometer Experiment, which will make temperature maps of the lunar surface; and the Miniature Radio Frequency, or Mini-RF, an experimental radar and radio transmitter that will search for subsurface ice and create detailed images of permanently-shaded craters.

The final instrument, the Lyman Alpha Mapping Project, will be activated after the other instruments have completed their calibrations, allowing more time for residual contaminants from the manufacture and launch of LRO to escape into the vacuum of space. This instrument is an ultraviolet-light imager that will use starlight to search for surface ice. It will take pictures of the permanently-shaded areas in deep craters at the lunar poles.

"Accomplishing these significant milestones moves us closer to our goals of preparing for safe human return to the moon, mapping the moon in unprecedented detail, and searching for resources," said LRO Project Scientist Richard Vondrak of NASA's Goddard Space Flight Center in Greenbelt, Md.

While its instruments are being activated and tested, the spacecraft is in a special elliptical commissioning orbit around the moon. The orbit takes less fuel to maintain than the mission's primary orbit. The commissioning orbit's closest point to the lunar surface is about 19 miles over the moon's south pole, and its farthest point is approximately 124 miles over the lunar north pole.

After the spacecraft and instruments have completed their initial calibrations, the spacecraft will be directed into its primary mission orbit in August, a nearly-circular orbit about 31 miles above the lunar surface.

Goddard built and manages LRO, a NASA mission with international participation from the Institute for Space Research in Moscow. Russia provides the neutron detector aboard the spacecraft.

LRO First Images

LRO First Images

These images show cratered regions near the moon's Mare Nubium region, as photographed by the Lunar Reconnaissance Orbiter's LROC instrument. Impact craters feature prominently in both images. Older craters have softened edges, while younger craters appear crisp. Each image shows a region 1,400 meters (0.87 miles) wide, and features as small as 3 meters (9.8 feet) wide can be discerned. The bottoms of both images face lunar north.

The image-lower left shows the location of these two images in relation to each other. The locator image shows an area 3,542 meters (2.2 miles) wide by 14,000 meters (8.7 miles) long. The scene is at the lunar coordinates 34.4 degrees South by 6.0 degrees West.

The right-lower image shows a raw image of the region photographed by one of the LROC cameras. Each band in this "venetian blinds" image is about 90 km (55.9 miles) wide. For comparison, the width of the locator image above is shown here as two white lines.

LRO Image of the Moon LRO Image of the Moon
